HomeSafe User’s Guide
Menu 3 LAN Setup 20-1
Chapter 20
Menu 3 LAN Setup
This chapter covers how to configure your wired Local Area Network (LAN) settings.
20.1 LAN Setup
This section describes how to configure the Ethernet using Menu 3 — LAN Setup. From the
main menu, enter 3 to display menu 3.
Figure 20-1 Menu 3 LAN Setup
20.1.1 General Ethernet Setup
This menu allows you to specify filter set(s) that you wish to apply to the Ethernet traffic. You
seldom need to filter Ethernet traffic; however, the filter sets may be useful to block certain
packets, reduce traffic and prevent security breaches.
Figure 20-2 Menu 3.1 LAN Port Filter Setup
If you need to define filters, please read the Filter Set Configuration chapter first, then return to
this menu to define the filter sets.
20.2 Protocol Dependent Ethernet Setup
Depending on the protocols for your applications, you need to configure the respective Ethernet
Setup, as outlined below.
¾
For TCP/IP Ethernet setup refer to the Internet Access Application chapter.
¾ For bridging Ethernet setup refer to the Bridging Setup chapter.
20.3 TCP/IP Ethernet Setup and DHCP
Use menu 3.2 to configure your HomeSafe for TCP/IP.
To edit menu 3.2, enter 3 from the main menu to display Menu 3 — LAN Setup. When menu 3
appears, press 2 and press [ENTER] to display Menu 3.2 — TCP/IP and DHCP Ethernet
Setup, as shown next
:
Menu 3.1 - LAN Port Filter Setup
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Press ENTER to Confirm or ESC to Cancel:
Menu 3 - LAN Setup
1. LAN Port Filter Setup
2. TCP/IP and DHCP Setup
5. Wireless LAN Setup
