HomeSafe User’s Guide
30-4 System Information and Diagnosis
30.2.2 Console Port Speed
You can set up different port speeds for the console port through Menu 24.2.2 – System
Maintenance – Console Port Speed. Your HomeSafe supports 9600 (default), 19200, 38400,
57600 and 115200 bps. Press [SPACE BAR] and then [ENTER] to select the desired speed in
menu 24.2.2, as shown in the following figure.
Figure 30-5 Menu 24.2.2 System Maintenance : Change Console Port Speed
30.3 Log and Trace
There are two logging facilities in the HomeSafe. The first is the error logs and trace records that
are stored locally. The second is the syslog facility for message logging.
30.3.1 Syslog Logging
The HomeSafe uses the syslog facility to log the CDR (Call Detail Record) and system messages
to a syslog server. Syslog and accounting can be configured in Menu 24.3.2 — System
Maintenance - Syslog Logging, as shown next.
Figure 30-6 Menu 24.3.2 System Maintenance : Syslog Logging
You need to configure the syslog parameters described in the following table to activate syslog
then choose what you want to log.
Table 30-3 Menu 24.3.2 System Maintenance : Syslog and Accounting
PARAMETER DESCRIPTION
Syslog:
Active Press [SPACE BAR] and then [ENTER] to turn syslog on or off.
Syslog Server IP
Address
Enter the IP Address of the server that will log the CDR (Call Detail Record) and
system messages i.e., the syslog server.
Log Facility Press [SPACE BAR] and then [ENTER] to select a Local option. The log facility
allows you to log the message to different files in the server. Please refer to the
documentation of your syslog program for more details.
When finished configuring this screen, press [ENTER] to confirm or [ESC] to cancel.
Menu 24.2.2 – System Maintenance – Change Console Port Speed
Console Port Speed: 9600
Press ENTER to Confirm or ESC to Cancel:
Menu 24.3.2 - System Maintenance - Syslog Logging
Syslog:
Active= No
Syslog Server IP Address= 0.0.0.0
Log Facility= Local 1
Press ENTER to Confirm or ESC to Cancel:
