HomeSafe User’s Guide
3-4 Connection Wizard
Key 1 to Key 4 The WEP keys are used to encrypt data. Both the HomeSafe and the wireless stations must
use the same WEP key for data transmission.
If you chose 64-bit WEP, then enter any 5 ASCII characters or 10 hexadecimal characters
("0-9", "A-F").
If you chose 128-bit WEP, then enter 13 ASCII characters or 26 hexadecimal characters
("0-9", "A-F").
You must configure all four keys, but only one key can be activated at any one time. The
default key is key 1.
Back Click Back to display the previous screen.
Next Click Next to proceed to the next screen.
If you choose Extend security in the Wireless LAN Setup screen, you can set up a Pre-Shared
Key.
Figure 3-4 Connection Wizard: Wireless LAN Setup: Extend Security
The following table describes the labels in this screen.
Table 3-3 Connection Wizard: Wireless LAN Setup: Extend Security
Pre-Shared
Key Type from 8 to 63 case-sensitive ASCII characters.
Back Click Back to display the previous screen.
Next Click Next to proceed to the next screen.
Refer to the chapter on wireless LAN for more information.
3.5 Connection Wizard : Screen 4
The HomeSafe offers three choices of encapsulation. They are Ethernet, PPP over Ethernet or
PPTP.
3.5.1 Ethernet
Choose Ethernet when the WAN port is used as a regular Ethernet.
