HomeSafe User’s Guide
Connection Wizard 3-3
Table 3-1 Connection Wizard : Wireless LAN Setup
LABEL DESCRIPTION
The level of Security can be selected as none, basic or extended. Choose No security to
have no wireless LAN security configured and proceed to the ISP Parameters for Internet
Access screen.
Choose Basic security if you want to configure WEP Encryption parameters.
Choose Extend security to configure a Pre-Shared Key.
The third screen varies depending on which security level you select.
Back Click Back to display the previous screen.
Next Click Next to proceed to the next screen.
)
The wireless stations and HomeSafe must use the same
ESSID, channel ID and WEP encryption key (if WEP is enabled)
for wireless communication.
3.4 Connection Wizard : Screen 3
If you choose Basic, you can setup WEP Encryption parameters.
Figure 3-3 Connection Wizard: Wireless LAN Setup: Basic Security
The following table describes the labels in this screen.
Table 3-2 Connection Wizard: Wireless LAN Setup: Basic Security
WEP
Encryption Select 64-bit WEP or 128-bit WEP to allow data encryption.
ASCII Select this option in order to enter ASCII characters as the WEP keys.
HEX Select this option to enter hexadecimal characters as the WEP keys.
The preceding “0x” is entered automatically.
