HomeSafe User’s Guide
Menu 3 LAN Setup 20-5
Table 20-3 Menu 3.2.1: IP Alias Setup
FIELD DESCRIPTION EXAMPLE
IP Alias 1, 2 Choose Yes to configure the LAN network for the HomeSafe. Yes
IP Address Enter the IP address of your HomeSafe in dotted decimal notation. 192.168.1.1
IP Subnet Mask Your HomeSafe will automatically calculate the subnet mask based
on the IP address that you assign. Unless you are implementing
subnetting, use the subnet mask computed by the HomeSafe. 255.255.255.0
RIP Direction Press [SPACE BAR] and then [ENTER] to select the RIP direction.
Options are
Both, In Only, Out Only or None. None
Version Press [SPACE BAR] and then [ENTER] to select the RIP version.
Options are
RIP-1, RIP-2B or RIP-2M.
RIP-1
Incoming Protocol
Filters Enter the filter set(s) you wish to apply to the incoming traffic
between this node and the HomeSafe. 1
Outgoing Protocol
Filters Enter the filter set(s) you wish to apply to the outgoing traffic
between this node and the HomeSafe. 2
When you have completed this menu, press [ENTER] at the prompt [Press ENTER to Confirm…] to save
your configuration, or press [ESC] at any time to cancel.
20.4 Wireless LAN Setup
Use menu 3.5 to set up your HomeSafe as the wireless access point. To edit menu 3.5, enter 3
from the main menu to display Menu 3 – LAN Setup. When menu 3 appears, press 5 and then
press [ENTER] to display Menu 3.5 – Wireless LAN Setup as shown next.
Figure 20-6 Menu 3.5 Wireless LAN Setup
The following table describes the fields in this menu.
Table 20-4 Menu 3.5 Wireless LAN Setup
FIELD DESCRIPTION EXAMPLE
ESSID
The ESSID (Extended Service Set IDentity) identifies the AP to which
the wireless stations associate. Wireless stations associating to the Wireless
Menu 3.5 - Wireless LAN Setup
ESSID= ZyXEL
Hide ESSID= No
Channel ID= CH06 2437MHz Edit MAC Address Filter= No
RTS Threshold= 2432 Edit Roaming Configuration= No
Frag. Threshold= 2432
WEP Encryption= Disable Preamble= Long
Default Key= N/A 802.11 Mode= Mixed
Key1= N/A
Key2= N/A
Key3= N/A
Key4= N/A
Authen. Method= N/A
Press ENTER to Confirm or ESC to Cancel:
