HomeSafe User’s Guide
20-2 Menu 3 LAN Setup
Figure 20-3 Menu 3.2 TCP/IP and DHCP Ethernet Setup
Follow the instructions in the next table on how to configure the DHCP fields.
Table 20-1 Menu 3.2: DHCP Ethernet Setup Fields
FIELD DESCRIPTION EXAMPLE
DHCP This field enables/disables the DHCP server.
If set to Server, your HomeSafe will act as a DHCP server.
If set to None, the DHCP server will be disabled.
If set to Relay, the HomeSafe acts as a surrogate DHCP server and
relays requests and responses between the remote server and the
clients.
When set to Server, the following items need to be set:
Server
Client IP Pool:
Starting Address This field specifies the first of the contiguous addresses in the IP
address pool.
192.168.1.33
Size of Client IP
Pool
This field specifies the size, or count of the IP address pool. 128
Menu 3.2 - TCP/IP and DHCP Ethernet Setup
DHCP= Server TCP/IP Setup:
Client IP Pool:
Starting Address= 192.168.1.33 IP Address= 192.168.1.1
Size of Client IP Pool= 32 IP Subnet Mask= 255.255.255.0
First DNS Server= From ISP RIP Direction= Both
IP Address= N/A Version= RIP-1
Second DNS Server= From ISP Multicast= None
IP Address= N/A Edit IP Alias= No
Third DNS Server= DNS Relay
IP Address= N/A
DHCP Server Address= N/A
Press ENTER to Confirm or ESC to Cancel: First address in
the IP pool
Size of the IP Pool
IP addresses of
the DNS
servers
This is the IP
address of the
HomeSafe
