HomeSafe User’s Guide
Remote Node Configuration 22-5
Table 22-3 Menu 11.1 Remote Node Profile for PPTP Encapsulation
FIELD DESCRIPTION EXAMPLE
Encapsulation Press [SPACE BAR] and then [ENTER] to select PPTP. You must
also go to menu 11.3 to check the IP Address setting once you have
selected the encapsulation method. PPTP
My IP Addr Enter the IP address of the WAN Ethernet port. 10.0.0.140
My IP Mask Enter the subnet mask of the WAN Ethernet port. 255.255.255.0
Server IP Addr Enter the IP address of the ANT modem. 10.0.0.138
Connection
ID/Name
Enter the connection ID or connection name in the ANT. It must
follow the “c:id” and “n:name” format.
This field is optional and depends on the requirements of your DSL
modem.
N:My ISP
22.3 Edit IP
Move the cursor to the Edit IP field in menu 11.1, then press [SPACE BAR] to select Yes. Press
[ENTER]
to open Menu 11.3 - Remote Node Network Layer Options.
Figure 22-4 Menu 11.3 Remote Node Network Layer Options for Ethernet Encapsulation
This menu displays the My WAN Addr field for PPPoE and PPTP encapsulations and
Gateway IP Addr field for Ethernet encapsulation. The following table describes the fields in
this menu.
Table 22-4 Remote Node Network Layer Options
FIELD DESCRIPTION EXAMPLE
IP Address
Assignment If your ISP did not assign you an explicit IP address, press [SPACE BAR]
and then [ENTER] to select Dynamic; otherwise select Static and enter
the IP address & subnet mask in the following fields. Dynamic
(default)
(Rem) IP
Address If you have a static IP Assignment, enter the IP address assigned to you
by your ISP.
(Rem) IP
Subnet Mask If you have a static IP Assignment, enter the subnet mask assigned to
you.
Gateway IP
Addr This field is applicable to Ethernet encapsulation only. Enter the gateway
IP address assigned to you if you are using a static IP address.
Menu 11.3 - Remote Node Network Layer Options
IP Address Assignment= Dynamic
IP Address= N/A
IP Subnet Mask= N/A
Gateway IP Addr= N/A
Network Address Translation= SUA Only
Metric= 1
Private= N/A
RIP Direction= None
Version= N/A
Multicast= None
Enter here to CONFIRM or ESC to CANCEL:
