HomeSafe User’s Guide
NAT 25-3
25.3.1 Address Mapping Sets
Enter 1 to bring up Menu 15.1 — Address Mapping Sets.
Figure 25-4 Menu 15.1 Address Mapping Sets
SUA Address Mapping Set
Enter 255 to display the next screen (see also section 25.1.1). The fields in this menu cannot be
changed.
Figure 25-5 Menu 15.1.255 SUA Address Mapping Rules
The following table explains the fields in this menu.
)
Menu 15.1.255 is read-only.
Table 25-2 SUA Address Mapping Rules
FIELD DESCRIPTION EXAMPLE
Set Name This is the name of the set you selected in menu 15.1 or enter
the name of a new set you want to create. SUA
Idx This is the index or rule number. 1
Local Start IP Local Start IP is the starting local IP address (ILA). 0.0.0.0
Local End IP Local End IP is the ending local IP address (ILA). If the rule is
for all local IPs, then the Start IP is 0.0.0.0 and the End IP is
255.255.255.255. 255.255.255.255
Global Start IP This is the starting global IP address (IGA). If you have a
dynamic IP, enter 0.0.0.0 as the Global Start IP. 0.0.0.0
Global End IP This is the ending global IP address (IGA).
Menu 15.1.255 - Address Mapping Rules
Set Name= SUA
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- --------------- ------
1. 0.0.0.0 255.255.255.255 0.0.0.0 M-1
2. 0.0.0.0 Server
3.
4.
5.
6.
7.
8.
9.
10.
Menu 15.1 - Address Mapping Sets
1. NAT_SET
255. SUA (read only)
