Chapter 23 Spanning Tree Protocol
IES-708-22A User’s Guide
172
Bridge Status
If STP is activated, the following fields appear. If STP is not activated, Disabled
appears.
Our bridge ID
This is the unique identifier for this bridge, consisting of bridge priority plus MAC
address. This ID is the same in Designated root ID if the IES-708-22A is the
root switch.
Designated root ID
This is the unique identifier for the root bridge, consisting of bridge priority plus
MAC address. This ID is the same in Our bridge ID if the IES-708-22A is the
root switch.
Topology change
times
This is the number of times the spanning tree has been reconfigured.
Time since change
This is the time since the spanning tree was last reconfigured.
Cost to root
This is the path cost from the root port on the IES-708-22A to the root switch.
Root port ID
This is the priority and number of the port on the IES-708-22A through which the
IES-708-22A must communicate with the root of the Spanning Tree. “0x0000”
displays when the IES-708-22A is the root switch.
Root max age
(second)
This is the maximum time (in seconds) the root switch can wait without receiving
a configuration message before attempting to reconfigure.
Root hello time
(second)
This is the time interval (in seconds) at which the root switch transmits a
configuration message. The root bridge determines Hello Time, Max Age and
Forwarding Delay.
Root forward delay
(second)
This is the time (in seconds) the root switch will wait before changing states
(that is, listening to learning to forwarding).
Max age (second)
This is the maximum time (in seconds) the IES-708-22A can wait without
receiving a configuration message before attempting to reconfigure.
Hello time (second)
This is the time interval (in seconds) at which the IES-708-22A transmits a
configuration message. The root bridge determines Hello Time, Max Age and
Forwarding Delay.
Forward delay
(second)
This is the time (in seconds) the IES-708-22A will wait before changing states
(that is, listening to learning to forwarding).
Port Status
This identifies the IES-708-22A’s ports that support the use of STP. If STP is
activated, the following fields appear. If STP is not activated, Disabled appears.
State
This field displays the port’s RSTP (or STP) state. With RSTP, the state can be
discarding, learning or forwarding. With STP, the state can be disabled,
blocking, listening, learning, or forwarding.
Disabled appears when RSTP has not been turned on for the individual port or
the whole device.
Port ID
This is the priority and number of the port on the IES-708-22A through which the
IES-708-22A must communicate with the root of the Spanning Tree. “0x0000”
displays when the IES-708-22A is the root switch.
Path cost
This is the path cost from this port to the root switch.
Cost to root
This is the path cost from the root port on the IES-708-22A to the root switch.
Designated bridge
This is the unique identifier for the bridge that has the lowest path cost to reach
the root bridge, consisting of bridge priority plus MAC address.
Designated port
This is the port on the designated bridge that has the lowest path cost to reach
the root bridge, consisting of bridge priority.
Table 51 Advanced Application > Spanning Tree Protocol (continued)
LABEL
DESCRIPTION
