A3 - 171
YASNAC PCNC Operating Manual APPENDIX 3: Parameter Tables
423 Manual skip contact direction
monitor No.4 Bit information D1: X+
D2:Y+ D3:Z+ D8:X-
D9:Y- D10:Z-
424 Manual skip contact direction
monitor No.5 Bit information D1: X+
D2:Y+ D3:Z+ D8:X-
D9:Y- D10:Z-
811 1st axis skip position 0.001mm -999999999 999999999 Coordinate values
when skip signal is
operating (1st axis)
812 2nd axis skip position 0.001mm -999999999 999999999 Coordinate values
when skip signal is
operating (2nd axis)
813 3rd axis skip position 0.001mm -999999999 999999999 Coordinate values
when skip signal is
operating (3rd axis)
814 4th axis skip position 0.001mm -999999999 999999999 Coordinate values
when skip signal is
operating (4th axis)
815 5th axis skip position 0.001mm -999999999 999999999 Coordinate values
when skip signal is
operating (5th axis)
920 Manual skip position data,
No.1 point 1st axis 0.001mm -99999999 99999999 Manual skip position
information, No.1 point
(X-Z).
921 Manual skip position data,
No.1 point 2nd axis 0.001mm -99999999 99999999 Manual skip position
information, No.1 point
(X-Z).
922 Manual skip position data,
No.1 point 3rd axis 0.001mm -99999999 99999999 Manual skip position
information, No.1 point
(X-Z).
923 Manual skip position data,
No.2 point 1st axis 0.001mm -99999999 99999999 Manual skip position
information, No.2 point
(X-Z).
924 Manual skip position data,
No.2 point 2nd axis 0.001mm -99999999 99999999 Manual skip position
information, No.2 point
(X-Z).
925 Manual skip position data,
No.2 point 3rd axis 0.001mm -99999999 99999999 Manual skip position
information, No.2 point
(X-Z).
926 Manual skip position data,
No.3 point 1st 0.001mm -99999999 99999999 Manual skip position
information, No.3 point
(X-Z).
927 Manual skip position data,
No.3 point 2nd axis 0.001mm -99999999 99999999 Manual skip position
information, No.3 point
(X-Z).
928 Manual skip position data,
No.3 point 3rd axis 0.001mm -99999999 99999999 Manual skip position
information, No.3 point
(X-Z).
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
