A3 - 14
YASNAC PCNC Operating Manual APPENDIX 3: Parameter Tables
6422 2nd axis, pitch error reference point
memory number 0 1151
6802 2nd axis, pitch error compensation
intervals 0.001mm 0 999999999
6812 2nd axis, second reference point
position 0.001mm -999999999 999999999
6822 2nd axis, third reference point posi-
tion 0.001mm -999999999 999999999
6832 2nd axis, fourth reference point
position 0.001mm -999999999 999999999
6862 2nd axis, pitch error compensation
stroke (maximum) 0.001mm -999999999 999999999
6872 2nd axis, pitch error compensation
stroke (minimum) 0.001mm -999999999 999999999
6882 2nd axis, pitch error comp reference
point position 0.001mm -999999999 999999999
6902 No.1 stored stroke limit 2nd axis (+) 0.001mm -999999999 999999999
6912 No.1 stored stroke limit 2nd axis (-) 0.001mm -999999999 999999999
8000 1 Absolute motor zero return condi-
tion 2nd axis 0 1
8001 1 Absolute motor position gap condi-
tion 2nd axis 0 1
8402 2nd axis, fine adjust amount in zero
point setting -32767 32767
8412 2nd axis, position gap distance limit
when ??? 0 32767
8472 2nd axis (- to +) roundness
irregularity Integral constant msec 0 32767
8482 2nd axis (- to +) roundness
irregularity completion torque 0.01% 0 20000
8492 2nd axis roundness irregularity
Timing parameter 0.01[1/S] -32767 32767
8522 2nd axis roundness irregularity
weight compensation torque 0.01% -12000 12000
8802 2nd axis, power off machine
position 0.001mm -999999999 999999999
8812 2nd axis, offset amount in zero point
setting pulse -999999999 999999999
8822 2nd axis, shift amount in zero point
setting 0.001mm -999999999 999999999
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
