A3 - 54
YASNAC PCNC Operating Manual APPENDIX 3: Parameter Tables
4013 0 Tool radius offset Start-up
and cancel motion
1: A type
0: B type 0 1
1 Tool radius offset switching point of
direction
1: Point of intersection switching at
start and end.
0: Point of intersection 0 1
2 Tool radius offset process after the
offset amount change
1: Valid from the start point
0: Valid from the completion point 0 1
3 Tool radius offset availability
of interference check
1: Valid
0: Invalid 0 1
4 Tool radius offset process after
detection of interference
1: Alarm
0: Automatic correction 0 1
4014 0 1st axis Direction of G60
unidirectional positioning
1: Minus
0: Plus 0 1
1 2nd axis Direction of G60
unidirectional
1: Minus
0: Plus 0 1
2 3rd axis Direction of G60
unidirectional positioning
1: Minus
0: Plus 0 1
3 4th axis Direction of G60
unidirectional positioning
1: Minus
0: Plus 0 1
4 5th axis Direction of G60
unidirectional positioning
1: Minus
0: Plus 0 1
4015 1 Allowable error range check
for circular arc
command
1: Checked
0: Not checked 0 1
4450 Small arc skip value in
tool radius compensation 0.001mm 0 32767
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
