A3 - 22
YASNAC PCNC Operating Manual APPENDIX 3: Parameter Tables
1754 4th axis Servo Damping, high pass
filter time
const
micro sec 0 32767
1784 4th axis contour compensation 2nd
coefficient 0.001times 0 32767
1794 4th axis Servo Damping, low pass
filter time
const
micro sec 0 32767
1804 4th axis contour compensation
coefficient 0.001times 0 32767
1814 4th axis Servo Damping,
compensation gain % -2000 2000
1824 4th axis Motion amount or table
rotation angle/motor rev 0.001mm 0 999999999
1834 4th axis load inertia % 0 32767
1844 4th axis separately PG, No.
of pulses / motor rev pulse 0 999999999
1854 4th axis Virtual C phase distance 0.001deg 0 999999999
2002 3 4th axis validity of automatic mode
handle 0 1
2464 4th axis rapid feed accel/decel time
constant msec 0 32767 Set multiple of 4
2484 4th axis backlash compensation
amount in G01 mode 0.1micron -32767 32767
2494 4th axis backlash compensation
amount in Handle 0.1micron -32767 32767
2504 4th axis accel/decel time
constant in feed cut msec 0 32767
2514 4th axis accel/decel time
constant in thread/tap msec 0 32767
2524 4th axis reference point return
approach speed mm/min,
deg/min
0 32767
2534 4th axis reference point return creep
speed mm/min,
deg/min
0 32767
2564 4th axis accel/decel time
constant in handle feed msec 0 32767 Set multiple of 4
2574 4th axis accel/decel time
constant in No2 G00 msec 0 32767 Set multiple of 4
2594 4th axis rapid feed accel/decel
S-curve 0 20
2604 4th axis rapid feed accel/decel
S-curve in 2nd S 0 15
2804 4th axis Rapid feed rate mm/min 0 240000
2814 4th axis rapid feed rate in 2nd
S-curve accel/dece mm/min,
deg/min
0 240000
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
