A3 - 78
YASNAC PCNC Operating Manual APPENDIX 3: Parameter Tables
1502 Solid tap synchronization offset
parameter K1 -32767 32767
1503 Solid tap synchronization offset
parameter K2 -32767 32767
1506 Rotary tool spindle sync offset
parameter K1 -32767 32676
1507 Rotary tool spindle sync offset
parameter K2 -32767 32676
1510 No. of teeth of gear A on the spindle
side tooth 0 32767 No. of teeth of gear A on
the spindle side for
spindle loop control
1511 No. of teeth of gear A on the spindle tooth 0 32767 No. of teeth of the spin-
dle intermediate gear A
used for spindle loop
control
1512 No. of teeth of gear A on the motor
intermediate tooth 0 32767 No. of teeth of the motor
intermediate gear A used
for spindle loop control
If there is no intermed-
iate gear, set 0
1513 No. of teeth of gear A on the motor
side intermediate tooth 0 32767 No. of teeth on the motor
side of gear A used for
spindle loop control
If there is no intermed-
iate gear, set 0
1514 No. of teeth of gear B on the spindle
side intermediate tooth 0 32767 No. of teeth of gear B on
the spindle side for
spindle loop control
If there is no intermedi-
ate gear, set motor side
one
1515 No. of teeth of gear B on the spindle
intermediate tooth 0 32767 No. of teeth of the
spindle intermediate
gear B used for spindle
loop control
If there is no intermedi-
ate gear, set 0
1516 No. of teeth of gear B on the motor
intermediate tooth 0 32767 No. of teeth of the motor
intermediate gear B used
for spindle loop control
If there is no intermedi-
ate gear, set 0
1517 No. of teeth of gear B on the motor
side tooth 0 32767 No. of teeth on the motor
side of gear B used for
spindle loop control
1540 Delay time to check the SAGR
signal msec 0 32767 If there is no intermedi-
ate gear, set 0
1551 1st axis backlash compensation
amount 0.1micron 0 32767
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
