Grass Valley K2 Summit Storage Area Network v.7.1 - Manual (Page 396)

26 October 2009 K2 Storage Area Network Installation and Service Manual 396
Renaming a K2 SAN
Renaming a K2 SAN
The requirements for renaming an existing K2 SAN are as follows:
• You must be logged in to the K2 System Configuration application with
permissions equivalent to K2 administrator or higher.
• The devices of the K2 SAN do not need to be offline, and there is no restart of
devices required.
To rename an existing K2 SAN, do the following:
1. In the K2 System Configuration application tree view, select the current name of
the K2 SAN, which is the top node of the storage system tree.
2. Click Rename . The Rename dialog box opens.
3. Enter the new name of the SAN and click Apply .
4. If the SAN name is used similarly in SiteConfig, make the appropriate change in
SiteConfig.
Adding devices to a K2 SAN
Refer to the following topics to add devices to an existing K2 SAN:
• “Adding a client device”
• “Adding an Ethernet switch”
• “Adding a K2 Media Server”
Add device Add in SiteConfig first, do network configuration
and software deployment. Then, add in K2Config
and configure using K2Config. —
Create a new site\SAN Use SiteConfig to create site, add devices,
configure network and deploy software, then
import into K2Config and configure each device —
Change hostname Perform hostname change using SiteConfig.
Remove and re-add to K2Config. If changing the
hostname of a media file system/metadata K2
Media Server, re-configure all clients on the K2
SAN using K2Config —
Change IP address (except
address of TOE on K2
Media Server) Use SiteConfig for IP address changes. Then in
K2Config, click on the changed device's network
configuration node. This refreshes the K2Config
view of IPs from the device. —
Change IP address of TOE
on K2 Media Server For TOE IP changes and/or TOE card removal,
use K2Config. —
Modify K2 SAN
redundancy - redundant to
non-redundant or vice
versa Use SiteConfig to recreate the site using the
appropriate redundancy models and configure
network and deploy software. Remove K2 SAN
from K2Config. Import site into K2Config.
Configure using K2Config. —
Operation Task flow context and policies Additional information
