Chapter 12 Administering and maintaining the K2 SAN
When you change a setting in one application, it is not automatically updated directly
in the other application. The applications do not communicate dynamically with one
another. However, both applications can read settings as currently configured on the
actual physical device and update their XML file accordingly. This is the method you
must use to keep the applications in synch.
When you change a setting that is managed by both applications, you should change
it first in SiteConfig, as a general rule. This application gives you the best context for
the system as a whole and provides features to identify and verify changes. Once the
change is implemented on the actual physical device, you must then open the relevant
page in the K2 System Configuration application. This causes the K2 System
Configuration application to refresh its settings from the device and write the change
to its XML file. It also allows you to verify your change within the context of the K2
System Configuration application.
The following table summarizes operations that involve interaction between
SiteConfig and K2Config.
Operation Task flow context and policies Additional information
Import SiteConfig system
description file into
K2Config Use this operation for initial install/commission
(greenfield) sites. First define the site topology
using SiteConfig and complete network
configuration and software deployment. Then
import the SiteConfig system description into
K2Config and complete the K2 SAN
configuration. This operation creates a K2 SAN in
K2Config with SiteConfig defined
devices. Uses the site name to check if
the K2 SAN already exists. The
operation will not import if the K2 SAN
exists with the same name. The
operation can import all sites which are
K2 SANs from a single system
description file in a single import step.
Import K2Config XML
into SiteConfig Use this operation when you're running SiteConfig
for the first time at a site with existing K2 SANs
that have already been configured with K2Config.
This allows you to seed the SiteConfig system
description with device information that is already
in the K2Config XML file. After you have done
this operation for the first time, do not do it again. This operation creates a SiteConfig site
with K2Config defined devices. The
operation removes all other sites.
Merge K2Config XML
into SiteConfig system
description Use this operation when you've already defined
some sites using SiteConfig and you later want to
bring in another K2Config defined K2 SAN that
doesn't exist in SiteConfig. Do not merge a
K2Config XML that you've already merged. If
you do so, it is likely that SiteConfig will create a
new site with the same devices. This operation creates a SiteConfig site
with K2Config defined devices but
leaves existing sites as is.
Rename Site\SAN Rename first in SiteConfig. Then rename in
K2Config. Do not import\merge into SiteConfig
or K2Config. —
Remove Site\SAN Remove first in SiteConfig. Then remove in
K2Config. Do not import\merge into SiteConfig
or K2Config. —
Remove device Remove from both SiteConfig and K2Config. —
