26 October 2009

K2 Storage Area Network Installation and Service Manual

318

Configuring the redundant server 2B

1. In the K2 System Configuration application tree view, select the K2 Media Server

you are configuring as server 2B.

2. Click the

Configure

button. The Configure K2 Server wizard opens. Follow the

on-screen text to configure the server for a Level 35R K2 SAN, as described in the
following table. Some screens require no input from you, as they are based on the
configurations already completed on a previously configured server.

On this page…

Do this…

Define server roles

If the K2 SAN has one or
more optional NH servers,
then FTP traffic should go to
the NH server, not the K2
Media Server you are now
configuring. In this case, do
not select the FTP server role
or the NAS server role.

Enter the name for the K2 Media Server. This should be the current
network name of the machine.
Select iSCSI bridge, FTP server, and NAS server.
Click

Next

Software Configuration

This page checks for the
software required to support
the roles you selected on the
previous page.

If software with Yes in the Required column reports as Not Installed, you
must first install it on the K2 Media Server before continuing. After
installing the software, click

Check Software

. When all required

software reports as Installed, click

Next

.
