26 October 2009

K2 Storage Area Network Installation and Service Manual

186

Configuring the redundant server B

2. Click the

Configure

button. The Configure K2 Storage System Server wizard

opens. Follow the on-screen text to configure the server for a Level 10R K2 SAN,
as described in the following table. Some screens require no input from you, as they
are based on the configurations already completed on a previously configured K2
Media Server.

On this page…

Do this…

Define server roles

Enter the name for the K2 Media Server. This should be the current
network name of the machine.
Enter the name or IP address of the Ethernet switch, as currently
configured on the switch, to which the K2 Media Server is connected.
Select all roles.
Click

Next

Software Configuration

This page checks for the
software required to support
the roles you selected on the
previous page.

If software with Yes in the Required column reports as Not Installed, you
must first install it on the K2 Media Server before continuing. After
installing the software, click

Check Software

. When all required

software reports as Installed, click

Next

.
