Project Builder User Interface
Ascent Xtrata Pro User's Guide 363
Before you start entering code you have to select the right sheet. To implement a field
formatting procedures you have to select the sheet for the project level, that means
the first sheet (tab 1). The dialog box caption is set to Project – Script Code.
To implement a general script locator, field extraction or validation methods, select
the field extraction scripts. The dialog box caption is set to Field Extraction – Script
Code. To implement template-specific methods, select the template’s field extraction
script. The caption for template field extraction sheets includes the template name,
<TemplateName> – Script Code.
Note
For each template a separate field extraction sheet is added to support template
specific extraction and validation procedures. The caption of the dialog box helps
you to verify that you have selected the right tab.
Object:
The Object list shows all the objects for the current module.
Proc:
The Proc list shows all the procedures for the currently selected object. Selecting an
item from the proc list that is not bold inserts the proper procedure definition for that
procedure into the code area.
Windows Close Button
If you change the code within the edit area, the changes are immediately saved. To
close the script code dialog box, click the window’s Close button in the upper right
corner of the window.
Table Model Properties Dialog Box
Use this dialog box to set up a table model.
