Kofax Getting Started with Ascent Xtrata Pro - Manual (Page 141)

Chapter 4
122 Ascent Xtrata Pro User's Guide
• Right-click the row for a locator and select Delete Locator from the context
menu.
• Select the row for a locator and click Delete Locator on the Extraction Design
toolbar.
When prompted to confirm the deletion, click Yes.
To rename a locator:
• Double-click the name of the locator to select the whole name. Then, type the
new name in place.
• Click the name of the locator and edit in place.
Note
Locator names must be unique for a class. If you enter a name that
already exists for another locator, a warning will display.
To access the properties for a locator:
• Right-click a locator and select Locator Properties from the context menu.
• Double-click a locator.
• Select a locator and click Locator Properties on the Extraction Design toolbar.
Exporting and Importing Locators
You might want to reuse a complex locator in another project or in another class of
the same project. Ascent Xtrata Pro provides options for reusing locators so they do
not have to be defined twice. Locators can be exported with all of their settings and
imported into another project or another class. Once a locator has been imported you
can either use it as is, or make modifications. In either case, this not only saves time,
but also reduces the potential for errors.
X To export a locator
1 Right-click the locator and select Export Locator from the context menu or
click Export Locator on the Extraction Design toolbar. The Export locator
dialog box displays.
2
Enter the name for the exported locator and the location for the locator file.
Locator files are saved with a file extension of “.loc.”
