Project Builder User Interface
Ascent Xtrata Pro User's Guide 313
Select one of the field data types from the drop list to generate sample script code
that corresponds to the selected field data type. You may copy the sample code to the
Script Editor to add it to your script.
Testing
To test the implemented script, enter some sample text and click Format. The sample
text is formatted as defined in the script and displayed in the output field.
Buttons
OK
Click this button to save your settings.
Cancel
Click this button to close the dialog box and discard any changes you made.
Show Script
Click this button to open the Sax Basic script editor to edit a script.
You can select the locator event “_FieldFormat”
and add your code. Close the script editor to return to the properties page. The
script is stored automatically in the project file.
Note
Make sure that your Script Formatter name does not start with a number
or contain any special characters such as blanks or underlines. Only properly
named Script Formatters are accessible in the script.
Help
Click this button to view the online Help topic for this dialog box.
Field Properties Dialog Box
There is a field properties dialog box for each type of field (simple or table).
Simple Fields Properties Dialog Box
Use this dialog box to define default results, set up general thresholds, and select and
define field formatting methods.
