Table 6-18 Displayed LU Information
Displayed item
Description
No summary
displayed
Summary
displayed
Product Model ID of the storage system
Serial
number S/N Serial number of the storage system
LUs Total number of LUs managed by HDLM among the
LUs in the storage system
Dynamic I/O
Path
Control -- The setting information about the dynamic I/O path
control function is displayed for each storage
system.
on: The dynamic I/O path control function is
enabled.
off: The dynamic I/O path control function is
disabled.
-: The dynamic I/O path control function is not
supported.
If an LU whose settings differ from the settings
based on the system storage unit is included, an
asterisk (*) is added after the on or off being
displayed.
iLU LU number of the storage system.
This number combined with the storage system
name (shown in DskName) identifies the LU that is
accessed by a path.
•
For the Lightning 9900V Series, Hitachi NSC55,
Hitachi Universal Storage Platform 100, Hitachi
Universal Storage Platform 600, Hitachi
Universal Storage Platform 1100, or HUS VM,
indicated by a hexadecimal number. The first
two characters of iLU are the CU number, and
the last two characters are the internal LU
number within the CU.
• For SVS, indicated by a hexadecimal number.
The first three characters of iLU are the CU
number, and the last two characters are the
internal LU number within the CU. The first
character of the CU number is the value 0.
• For XP20000/XP24000, P9500, or XP7,
indicated by a hexadecimal number. The first
two characters of iLU are 00, the middle two
numbers are the CU number, and the last two
characters are the internal LU number within
the CU.
• For the Thunder 9500V Series, Hitachi
2000/AMS/WMS/SMS series, or HUS100 series
indicated by a decimal number. The entire
value of iLU is the internal LU number within
6-64
Command Reference
Hitachi Dynamic Link Manager (for Solaris) User Guide
