28 Brocade Mobility 5181 Access Point Product Reference Guide
53-1002516-01
Mounting a Mobility 5181 Access Point
2
Ensure the cable length from the Ethernet source (host) to the Power Tap (or Power Injector) and
access point does not exceed 100 meters (333 ft). Neither the Power Tap or Power Injector has an
On/Off switch. Each receives power as soon as AC power is applied.
3. For Power Tap installations, have a certified electrician open the Power Tap enclosure, feed the
power cable through the unit’s LINE AC connector, secure the power cable to the unit’s three
screw termination block and tighten the unit’s LINE AC clamp (by hand) to ensure the power
cable cannot be pulled from the unit and is protected from the elements.
4. For Power Tap installations, attach a ground cable between the EARTH GROUND connector (on
the back of the unit) to a suitable earth ground connection as defined by your local electrical
code.
5. Verify all cable connections are complete before supplying power to the access point.
Power Injector LED Indicators
NOTE
The Mobility 5181 Access Point Power Tap (Part No. AP-PSBIAS-5181-01R) does not have LED
indicators.
The Power Injector demonstrates the following LED behavior under normal and/or problematic
operating conditions:
Mounting a Mobility 5181 Access Point
The Mobility 5181 Access Point can be connected to a pole or attach to a wall. Choose one of the
following mounting options based on the physical environment of the coverage area. Do not mount
the Mobility 5181 Access Point in a location that has not been approved in a site survey.
Refer to the following, depending on how you intend to mount the Mobility 5181 Access Point:
• Mobility 5181 Access Point pole mounted installations
• Mobility 5181 Access Point wall mounted installations
Mobility 5181 Access Point pole mounted installations
Complete the following steps to mount the Mobility 5181 Access Point to a (1.5 to 18 inch
diameter) steel pole or tube (using the mounting bracket):
LED AC (Main) Port
Green (Steady) Power Injector is receiving power from an
AC outlet. Indicates a device is connected to
the Power Injector’s outgoing Data
& Power cable.
Green (Blinking) Output voltage source is out of range. The Power Injector is overloaded or
has a short circuit.
