371
Security Area #1-8 SA 1 to SA 8 Alphanumeric Up to 12 characters.
This optional field specifies the name of a Security Area
that the cardholder may access. There can be eight
Security Areas
Additional Security Areas are assigned to a cardholder
when there are access privileges required that are
different than those already assigned.
Time Zone for
Security Area #1-8 SA 1 TZ
to
SA 8 TZ Numeric Up to 3 characters.
This field specifies the Time Zone number that applies to
a Security Area assigned to a cardholder.
Social Security
Number SSN Numeric 9 characters.
Data for this reference field is transmitted with contiguous
numbers. For example, if the Social Security Number is
555-12-3456, data is transmitted as: 555123456
Card Status STATUS Numeric 1 Digit. Enter one of the following values for each card:
VALUE: DESCRIPTION:
0 OK: This is the default.
1 Lost: Access is denied.
2 Stolen: Access is denied.
3 Inactive
4 Terminated
Supervisor’s
Name SUPRVISR Alphanumeric Up to 32 characters.
This is a reference field that may be used at the option of
the system owner.
Cardholder’s
Telephone
Extension TELEPHON Numeric Up to 6 characters.
This is a reference field that may be used at the option of
the system owner.
The default is 000000.
Badge Template TEMPLATE Alphanumeric Up to 8 characters.
This field defines the Photo badge template file name
Trace District TR DIST
Trace Time Zone TRACE TZ Numeric Up to 3 characters.
If 0 (zero) is entered, this feature is not active.
This field specifies during which Time Zone a
cardholder’s card activity is to be traced. The Time Zone
number is entered.
User Defined Field
#1 through User
Defined Field 4 USERFLD1 to
USERFLD4 Alphanumeric Up to 24 characters.
User defined fields can be set up by the operator for use
in storing additional reference information on
cardholders. This is usually a type of information that is
unique to the site or facility.
Functional Field
Name Protocol Field
Name
Type of Value Description
