91 SiteOmat Setup and Maintenance Manual – MDE 4817G
Kaizen
4-6.4. TLG Settings
An external TLG (Tank Level Gauging) can be defined by the Wizard. The Wizard allows setting
of a TLG system controlling up to 16 probes (numbered 1 to 16), where a single probe is connected
to each tank (manifold tanks cannot be defined by the Wizard).
If serial communication between the TLG console and the Controller is selected, the TLG is
allocated on Main 8Port: 192.168.1.111 port 3005.
NOTE
8-Mechanical Dispensers Islander PLUS pedestals
do not support connection to external TLG consoles.
4-6.5. Naming Conventions
The following naming conventions are used by the Wizard when defining communication channels
and system peripherals:
a. All buses' names begin with BUS_
b. The name of the buses on 8Port Commverters of peripheral controllers (Extension Box/ICR
PLUS), which are used only for interfacing pumps, begins with BUS_[ps name]
c. OrPTs naming is ORPT_[type]_[number], where:
• [type] is the type of the controller, i.e. ICRW stands for ICR PLUS with Pump
Controller, ICR stands for ICR PLUS without Pump Controller
• [number] matches the setup sequence as shown to the user on Page 3 of the Wizard
• Main ORPT is named ORPT
d. The name of a Printer is identical to the one of the OrPT to which it is connected, with the
addition of the suffix _Printer (Main printer is named Printer)
4-6.6. Cluster Log Port Conventions
The following convention is used by the wizard when defining unique log ports per cluster on
OrCU IP:
9000+100+10+Cluster → for Main Controller
9000+200+10*Extension No. + Cluster → for Extension Boxes
9000+300+10*ICR PLUS No. + Cluster → for ICR PLUS with Pump Controller
NOTE
For further information, please refer to paragraph 8-
4.
