background image

159

SiteOmat Setup and Maintenance Manual – MDE 4817G

Cluster

According to the selected Pump Server, select the cluster from the drop-

down list (see paragraph 7-10.2).

Printer

Select the Printer to be linked to the pump from the drop-down list, or click

on the ellipsis (…) button to open the Printer dialog box (see paragraph 7-4).

Reader

Select the device Reader to be linked to the pump from the drop-down list,

or click on the ellipsis (…) button to open the Reader dialog box (see

paragraph 7-6).

OrPT

Select the OrPT terminal to be linked to the pump for prompts display from

the drop-down list, or click on the ellipsis (…) button to open the OrPT

dialog box (see paragraph 7-5).

This association applies for this function only; the terminal can serve and be

linked to several pumps in the station.

7-11.2. Message Factors

The Message Factors define the format of the data displayed to the customer and the operator. The

location of the decimal point in the string of digits that make up the data can be set. To select a

format, click on the drop-down list.

The message factors are (see Table 7-5):

Table 7-5. Message Factors

Factor

Description

Volume

Volume of the pumped fuel in this transaction.

Totalizer Volume

Accumulative volume pumped in all transactions.

Preset Volume

Preset volume for pump authorization.

Price Per Volume (PPV)

Price Per Volume (PPV) for all transactions.

Amount

Payment (value) in this transaction.

Totalizer Amount

Accumulative payment pumped in all transactions.

Preset Amount

Preset amount for pump authorization.

NOTE

To ensure the system works out correctly, all

message factors for Gilbarco need to be set to .XXX.

7-11.3. Specific

Each dispenser type has specific parameters that need to be defined in this section.
