background image

43

SiteOmat Setup and Maintenance Manual – MDE 4817G

SECTION 3

OrCU ADMINSTRATION SCREEN

3-1. GENERAL

The SiteOmat Station Controller is factory set with the general configuration required for its proper

operation. However, settings may be modified in the OrCU Administration screen (see

Figure 3-2) according to location or network specifications.

3-2. TECNICIAN PC SOFTWARE REQUIRMENTS

The following software must be installed on the technician's PC prior to the controller setup

process:

1. OS – Microsoft Windows 2000/XP/2003

2. Microsoft Internet Explorer 7 or a higher version.

3. Sun Microsystems Java application (Can be downloaded from http://Java.com)

3-3. INITIAL SETUP PROCEDURES

To set the initial Controller configuration, proceed as follows:

1. Follow steps 1 to 10 described in section 2-6 above

2. Turn on the browser and type the default IP address for the OrCU Administrator screen:

o

http://192.168.1.104:8090

o

https://192.168.1.104:8090

(for BSP ver. 1.08 SP 9 and up)

The login dialog box appears (see Figure 3-1)

NOTE

For cases where the OrCU default IP was changed or

the IP is unknown, see paragraph 8-12.
