76

SiteOmat Setup and Maintenance Manual – MDE 4817G

NOTES

Pumps with identical Head number cannot be

connected to the same Cluster (IP and Port) on an 8-

Port Module Card.

4. Select the OrPT terminal to be linked to the pump for prompts display from the Connected

to OrPT

drop-down list (This setting is optional, the Wizard displays a warning notification

in cases where not all pumps were connected to an OrPT but does generate a validation

error)

5. Set the pump to the Tank the pump is actually connected to (Mandatory setting, if not set

the Wizard displays the following error notification: Select tank for all pumps)

6. Select the Product from the drop down list containing all products in use as defined on Page

5. This field is auto-populated based on tank selection

7. Select the Rate, namely the number of pulses per Liter/Gallon as required for mechanic

pumps setup only, using the drop-down list (10,100,1000)

8. Enter the F.P. Plus logical channel for communication with the controller (if F.P. Plus is in

use, as defined on page 4). Enter a different channel (between 1 and 16) for each pump. The

Wizard provides the user with the following error notifications in cases where an incorrect

value was entered:

a. VIS Channel must be less than 16

b. You connected same VIS channel to two pumps

9. For pumps that support Satellite linked nozzles (two nozzles connected to the same pump

head allowing simultaneous refuel from both sides of a truck), enter the second nozzle F.P.

Plus channel (between 1 and 16 and not previously used)

10. Click Next to continue

NOTE

The Setup Wizard supports one-grade dispensers

only. For other configurations, run the Wizard and

then set up the nozzles on the Main Setup screen

(refer to paragraph 4-5).
