SiteOmat Setup and Maintenance Manual – MDE 4817G

Table 4-2. Network Addresses for Controller Devices

Device

Default IP Address

Starting IP

Address

Ending IP

Address

TCP Ports

OrCU LAN1

(FCC)

192.168.1.104

8 Port

CommVerter

192.168.1.111

192.168.1.130

3001-3008

WGT Master

192.168.1.170

N/A

WGT

192.168.1.171

192.168.1.190

3001-3008

OrPT

192.168.1.211

192.168.1.230

3000

Receipt Printer

192.168.1.211

192.168.1.230

3485

8 Port Commverters are available on the Main Controller, Extension Boxes and ICR PLUS units

with Pump Controllers.

The Wizard allocates IP addresses first to Extension Boxes and then to ICR PLUS units. A

maximum of 10 peripheral controllers can be defined by the Wizard. In cases where more than

one peripheral is in use, configure the peripherals' IP (Extension Box and ICR PLUS factory set

default IP is 192.168.1.212).

For further details, please refer to 8-Port Commverter Operation and Installation Manual, P/N

MDE-4820.

4-6.2. Cluster Port Allocation

A Pump Server is defined per selected pump type. The number of clusters per Pump Server and

their IP/Ports depends on the selected Controller and on the selected pump.

NOTE

Cluster port allocation for Extension Boxes and ICR

PLUS pedestals is identical to 4-Mechanical

Dispensers Islander PLUS defaults.

4-6.3. Pump Clustering Conventions

The Wizard gathers pumps of the same type together. In cases where the user randomly defines

different pump types, the Wizard arranges the pumps by type, scanning the user's definition to find
