32 SiteOmat Setup and Maintenance Manual – MDE 4817G
2-4. ETHERNET NETWORK ADDRESSES
2-4.1. Network Addresses for Controller Internal Devices
Table 2-1 lists the IP addresses for the internal devices in the Controller system.
Table 2-1. Network Addresses for Controller Devices
Device Default IP Address Starting IP
Address
Ending IP
Address
TCP Ports
OrCU Ethernet 0
(FCC)
192.168.1.104 192.168.1.104
8 Port
CommVerter
192.168.1.111 192.168.1.111 192.168.1.130 3001-3008
WGT Master 192.168.1.170 192.168.1.170 N/A N/A
WGT 192.168.1.171 192.168.1.171 192.168.1.190 3001-3008
OrPT 192.168.1.211 192.168.1.211 192.168.1.230 3000
Receipt Printer 192.168.1.211 192.168.1.211 192.168.1.230 3485
Where:
• Default IP is the IP addresses defined prior to delivery
• Starting IP Address is the first IP number in the range allocated for the device
• Ending IP Address is the last IP number in the range allocated for the device
For example, the range to the OrPT is 211 to 230 or a maximum of 20 OrPT devices in the station.
NOTE
IP addresses can be modified according to local
network requirements.
2-4.2. Serial Addresses for Controller Devices
Table 2-2 lists the setup addresses of devices, required for the configuration of the Controller.
