SiteOmat Setup and Maintenance Manual – MDE 4817G
LAN2
192.168.2.104
172.25.138.195
ORCU
LAN1
192.168.0.104
Interne
t
Station
Router
192.168.2.1
Switch
VPN Router
172.25.138.193
Ports 22 , 443 192.168.2.104
Switch
CWGT
192.168.0.1
Head Office
10.180.0.3
MWGT
192.168.0.2
Figure 9-4. Example of Advanced Network Settings
9-4. DIAL UP MODEMS
9-4.1. Overview
The OrCU supports a variety of modems for Dialup connection. The OrCU (RAS) waits for
incoming call, answers and establishes a PPP connection. Then the access to the OrCU is done via
predefined (hardcoded) IP address, IP=172.31.0.1.
9-4.2. OrCU Settings
Each Modem type should to be set differently according to its baud rate and init string.
The modem settings are done through the OrCU Administrator screen.
1. Browse to the OrCU admin screen (IP=xx.xx.xx.xx:8090)
2. User: admin, password : admin
3. Click on Set Serial/ Modem Settings. The OrCU Serial/ Modem Settings screen is
displayed (see Figure 9-5)
4. Select the relevant baud rate and init string (according to the modem type - see below)
