152
SiteOmat Setup and Maintenance Manual – MDE 4817G
7-9. VIS AND WGT
NOTE
Only VIS and WGT systems are applicable in
Gasboy settings.
To open the VIS (Vehicle Identification System) dialog box (see Figure 7-21), select the VIS tab in
the Setup screen. This dialog box is intended for Controllers that include VIS and/or WGT and
enables users to define the attributes of these devices.
Each device requires setting of:
1. Name: The name identifying the device
2. Bus: Select the bus from the drop-down list or click on the ellipsis button (…) for a prompt
display of the Buses screen, and selection of the bus
3. Model: Select the device model from the drop-down list. There are three available models:
VIT, uVIT with 8 channels and WGT with 16 channels
4. Address: Click on the Hex radio button and enter the Hex Address in the appropriate box.
Refer to Table 2-2 for further details.
Click New or Modify (for update procedure) to enter the selection in the upper VIT list.
Click Close to return to the Setup screen.
Figure 7-21. Setup VIS Dialog Box
