149 SiteOmat Setup and Maintenance Manual – MDE 4817G
7. Click New to save the settings for a newly added product.
Click Modify if an existing product was edited
8. Click Close to return to the Setup Tanks dialog
To delete a product from the list, select it by clicking on its row. Once its parameters are displayed,
click Delete.
NOTE
A product in use cannot be deleted or modified:
disassociate the product from the tank, and the then,
disassociate the tank from the pumps.
7-8.3.3. Defining a Blended Product
If defining a blended product composed of two base products stored in two different tanks:
4. In the Product1 drop-down, select the previously defined base product
5. In the Product2 drop-down, select the previously defined base product to be added to the
blend
6. In the Percent of Product2 drop-down, select the percentage of the second fuel in the
mixture
7. Click New to save the settings for a newly added blended product.
Click Modify if an existing blended product was edited
8. Click Close to return to the Setup Tanks dialog
NOTE
To set a price for the blended product, please refer to
Section 5-6.
7-8.4. Defining a Virtual Tank for Blended Fuel
To support a blended product, a virtual tank composed of the two tanks to which the nozzle is
connected should be defined.
These virtual tanks will neither be shown in Tank Status screen nor be available in Wet Stock
Management for inventory and delivery.
As these are virtual tanks, TLG probes cannot be connected to them. Still, the amount dispensed
from the blended product nozzles will be included when calculating reconciliation for each of the
base tanks (transaction volume multiplied by percentage of fuel in the mixture).
Proceed as follows:
1. Define the two base-tanks
2. Define the blended product
3. In the Fuel Type drop-down, select the blended product
4. Select Tank1 (the tank that contains Product1)
5. Select Tank2 (the tank that contains Product2)
6. Click New to save all the settings
