Gasboy SiteOmat Maintenance Manual User Manual
Page 37

33
SiteOmat Setup and Maintenance Manual – MDE 4817G
Table 2-2. Serial (HEX) Addresses for Devices
Device
Default Address
Starting Serial
Address
Ending Serial
Address
OrTR (Orpak Tag Reader)
0x61
0x61
0x69
OrPT (Orpak Payment Terminal)
0x46
0x46
N/A
Printer
0x70
0x70
0x74
Journal Printer
N/A
0x1
N/A
Wireless Gateway
0x31
0x31
N/A
NOTE
The HEX address configured in the controller must
match the device HEX address. Otherwise, the
device is not loaded.
An example of address configuration for Islander PLUS and CFN controllers is displayed in
Figure 2-2 and Figure 2-3 respectively; examples for an Extension Box and ICR PLUS in
Figure 2-4 and Figure 2-5.
