137 SiteOmat Setup and Maintenance Manual – MDE 4817G
7-6. TAG READERS
To open the Tag Readers dialog box (see Figure 7-7), select the Tag Readers tab in the Setup
screen.
To define a reader, type its Name, then select its Bus. All readers supported in SiteOmat
communicate in Orpak frame. Click on the ellipsis (…) button for a prompt display of the Buses
screen, and selection of the bus.
Select the reader Model from the drop-down list:
• MiTag: MiTag tags reading device
• Orpak Tag Reader (OrTR): MiTag tags reading device, including an LCD screen
• UPI. Reading device that accepts old FuelOpass tags only
Next, define its Hex Address in the appropriate box. Refer to Table 2-2 for the serial address of the
Tag Readers.
Select the Association Model checkbox to use the Tag Reader for reading tag strings that define a
Fleet. This setup is necessary for Fleet Management. In this mode, the Tag Reader serves for fleet
authorization, and cannot be used for fuelling authorization.
Click New or Modify (for update procedure) to enter the selection in the upper Tag Reader list.
Click Close to exit from the Tag Reader screen and return to the Setup screen.
Figure 7-7. Tag Reader Dialog Box
