times, perform a Black Shading calibration again when you revert to shorter exposure times (1/ 4 th

sec or shorter) either in Timelapse, Normal or Varispeed modes.

ENABLE

After making any adjustments in the Time-lapse menu, check the Enable box to enter these values and
enable the Time-lapse record mode. The UI indicates by changing the top left frame rate display from

fps

TL, and the lower right audio level display to TIMELAPSE. Default is INTERVAL.

TRIGGER MODE: Specifies if the camera is to use a fixed Interval of time or wait for a side record com-

mand or external GPI contact closure to initiate the next frame capture.

1. To select and adjust, use joystick to highlight ENABLE checkbox.
2. Push in or down on joystick to place checkmark in ENABLE checkbox.
3. TRIGGER MODE box will highlight to allow you to choose between INTERVAL and ONE SHOT (default

is INTERVAL).

4. Twist joystick to change the highlighted TRIGGER MODE box to the desired setting.
5. Move joystick right to exit.
INTERVAL: The camera waits for the period of time defined by the Interval parameter. See INTERVAL.
ONE-SHOT: The camera waits for a side record command or external GPI contact closure.

SPEED

Specifies the shutter speed to be used during Time-lapse. This control is the same as is available in the
Shutter menu, but it provides access to additional shutter speeds that may be used in Time-lapse record-
ing. Default setting is 1/48 sec.

To adjust: Select SPEED and twist joystick to change the highlighted

SHUTTER SPEED box to the desired setting.
The additional exposure time presets are 1/2, 1/3 1/4, 1/6, 1/8, 1/12, 1/16, 1/24, 1/25, 1/30, 1/32, 1/33,

1/40, 1/48, 1/50, 1/60, 1/96, 1/100, 1/120, 1/125, 1/192, 1/200, 1/250, 1/384, 1/400, 1/500, 1/696, 1/800,

1/1000, 1/1200, 1/2000.
