6. Allow for an even amount of play on both sides of the lens focus marker. There should be a depth of

field range of several inches, so it is best to allow for good focus on either side of the exact distance

marker.

7. Tighten the camera focus ring screws, and retest focus. Screws should be tightened to approx. 22.22

In-Lb of Torque. Some shifting may occur while tightening the focus ring.

8. The “Edge Highlight” option in the viewfinder menu is a handy tool (if viewfinder is installed), and can

serve as a good double-check for proper focus.
