RED ONE OPERATION GUIDE - Manual (Page 136)

Build 31 v31.6.16
NOVEMBER 28, 2011
© 2007-2011 RED.COM INC.
135
GENLOCK INPUT
A single DIN 1.0/2.3 coaxial connector accepts a Tri-Level Sync signal for video genlocking.
When operating at 23.98, 24.00, 25.00 or 29.97 Project Time Bases, set the genlock signal generator to
SMPTE 274 progressive scan format, at the same frame rate as the project TIME BASE. Do not use PsF
or interlaced signals.
Using an Ambient ACL202CT, set dip switches as follows: D = down, U = up, R = right, L = left
NOTE: After changing any of the above dip switch settings, power cycle the Ambient ACL202CT
Lockit Box timecode unit.
Frame Rate Dip Switch Settings
23.98 fps 1D, 2U, 3D, 4D, 5U, 6U, 7U, AR, BR
24.00 fps 1D, 2U, 3U, 4D, 5U, 6U, 7U, AR, BR
25.00 fps 1U, 2U, 3U, 4D, 5U, 6U, 7U, AR, BR
29.97 fps 1D, 2D, 3U, 4D, 5U, 6U, 7U, AR, BR
When operating at 50.00 or 59.94 Project Time Bases, set the genlock signal generator to SMPTE 296
progressive scan format, at the same frame rate as the project TIME BASE.
Using an Ambient ACL202CT, set dip switches as follows:
D = Down, U = up, R = right, L = left
Frame Rate Dip Switch Settings
50.00 fps - settings not verified at this time -
59.94 fps 1D, 2D, 3U, 4D, 5U, 6D, 7U, AR, BR
Connect the camera Genlock input to the ACL202CT VIDEO/WORD output using a BNC cable.
Pin: Signal Description Direction
Center GENLOCK SMPTE 274M-2005 Tri-level Sync In
Shield/Screen GROUND Camera ground --
Genlock Input Signal
PROGRAM (DUAL-LINK) HD-SDI
Two DIN 1.0/2.3 connectors labeled HD-SDI support progressive scan HD Program signals.
Pin: Signal Description Direction
Center HD-SDI SMPTE-292M HD-SDI Out
Shield/Screen GROUND Camera ground --
Program HD-SDI Output (each connector)
