NOTE: Displays TINT if camera is not in master / slave configuration; displays TINT, S TINT, S
WBAL, and S FLUT if cameras are in master / slave configuration.
NOTE: S TINT, S WBAL, and S FLUT provide an offset for the slave camera relative to the common
TINT, WBAL and FLUT values programmed from the Master camera. This compensates for any
colorimetry differences between the transmitted and reflected light paths of an optical beam-
splitter.
• SHUTTER MODE and SYNCRO commands
• GENLOCK enable / disable command
• VARISPEED and RAMP commands
• TIMELAPSE commands
• LOOK commands (excluding FLUT parameter)
• ZEBRA 1/2 set up and enable / disable commands
• MEDIA FORMAT, CHANGE, RESET, and UNMOUNT commands
• PROJECT RESOLUTION, QUALITY and REDCODE command
• JAM SYNC enable / disable command
• FRAME GUIDE and USER AREA setup commands
NOTE: X POSN and Y POSN offset programmed for User Action or Title from the Master camera
will result in an equal but opposite offsets for the Slave camera.
• TEST SIGNAL commands
• USER KEY 3, 4 set up and enable / disable command
• USER KEY 5 set up and enable / disable command
FORMTATTING MEDIA
After making sure the master and slave camera each have the same size media attached, use the master
camera to format the media. Refer to APPENDIX B: MANAGING DIGITAL MEDIA .
RECORDING
The master camera initiates recording of the master AND slave cameras. Recording CANNOT be initiated
by the slave camera.
RECORD: Using RECORD key, the slave camera will enter record within +/- 2 frames of master.
GPI: Under GPI trigger, the Slave camera will enter record within +/- 1 frame of Master. This trigger must
be set up on each camera individually before powering down, connecting cameras together and powering
back up.
