Build 31 v31.6.16

NOVEMBER 28, 2011

SENSOR MENU CONTROLS

This section describes how to set sensor specific menu parameters including Sensitivity, Shutter Speed,

Color Temperature, Varispeed and Time-lapse.
To access the Sensor main menu push the SENSOR menu button on the rear of the camera. To enter the

available sub-menus, use the joystick to highlight the desired selection and push joystick in or down.

NOTE: Sensitivity and Color Temperature metadata values are stored as metadata and are also

used to modify the RED LCD, RED EVF, Preview HD-SDI and HDMI monitor outputs. They do not
affect 12-bit REDCODE RAW data recording; the stored metadata values may be used by

REDCODE RAW compatible NLE and image processing applications if desired.

SENSITIVITY

The sensitivity sub-menu allows you to adjust the camera’s ISO Rating.

ISO RATING

The sensitivity value is adjustable in 1/3

stop increments. When sensitivity is adjusted, the camera

metadata logs the change and the monitor path reacts accordingly.

1. To adjust, twist joystick to change the highlighted RATING box to the desired setting.
2. Push up on the joystick to set and return to the previous menu (SENSOR main menu) or push the EXIT

button to exit the menu completely.

MYSTERIUM
Adjustable in 1/3

stop increments from ISO 100 to ISO 2000. Default ISO RATING is ISO 320.

MYSTERIUM X
Adjustable in 1/3

stop increments from ISO 100 to ISO 6400. Default ISO RATING is ISO 800.
