• Master / Slave Indicator: Indicates camera as

Master (M) or Slave (S) when cameras are con-

nected together

• Shutter Speed: Current exposure time
• White Balance: Current color temp
• Cursors: Reference cursors – Safe Action, Safe

Title, Picture Center

• Frame Guide: Film projection area
• Timecode: Current timecode value
• Next Clip Filename: Displays the filename of

the next clip that will be shot

• Media / Quality: Specifies media location and

REDCODE setting

• Format: Current video recording format, 4K

RAW in this example

• Project Frame Rate: Current project frame

rate, 23.98 fps in this example

• Histogram: Histogram of current view with un-

der/overexposure bars on ends

• Raw Level Meter: Current sensor RAW peak

exposure levels

• Raw Clip Meter: Current sensor RAW clipping

status

• Raw Noise Level Bar: Relative area of pixels in

noise at the sensor

• Raw Clip Level Bar: Relative area of pixels in

clipping at the sensor

• Drop: Indicates the number of frames that have

been dropped during recording of the clip

• Temperature: Current camera temperature sta-

tus

• Media: Remaining media capacity in %
• Power: Remaining battery capacity in % or

connection to DC power (as shown)

• Audio Meter: Current audio inputs and levels
• EVF Menu: Displays available EVF options (RED

EVF Only)

• Gray Scale: Displays Gray Scale bar
