HAPSITE ER Operating Manual
The following status items are reported in the Service Module Tab Properties
Window. Refer to
Figure 15-7
.:
Supply Volts (V) . . . . . . . . . . . . . . . The voltage being supplied to the HAPSITE
(normally about 24).
UPS Battery (V) . . . . . . . . . . . . . . . The Uninterrupted Power Supply (UPS)
voltage, nominally 24 V.
Battery Level (%) . . . . . . . . . . . . . . Displays the charge percentage of the
HAPSITE battery (inserted in the battery
compartment of the Service Module), as a
percentage of the nominal design capacity.
Displays “No Battery" if a battery is not
installed.
Board Temp (C) . . . . . . . . . . . . . . . Displays the temperature near the processor
board in the Service Module in degrees
Celsius.
Turbo Speed (Hz) . . . . . . . . . . . . . . Indicates the speed of the Turbo Pump in
Hertz (equivalent to rotational speed in
revolutions per second).
Turbo Current (A) . . . . . . . . . . . . . Indicates the current draw of the Turbo Pump
in amperes.
Total Press (Pa). . . . . . . . . . . . . . . . The vacuum pressure in the Mass
Spectrometer in Pascals.
15.6 Starting Up HAPSITE on the Service Module
CAUTION
Damage to the Turbo Pump may result from moving the
Service Module while the Service Module pumps are
operating.
NOTE: If the Service Module must be moved and the HAPSITE is Attached (Turbo
Pump is running), first Detach the HAPSITE. See
.
Before turning on power to the Service Module, refer to
for the physical setup instructions.
Power for the HAPSITE is provided through the Service Module, as long as the
Service Module is connected to a power source and turned on. Turn on the
HAPSITE by pushing the POWER button on the outside front door.
