Accesses Data File information.

Returns the current screen to the System Setup screen.

Accesses ER IQ software information.

Accesses the Calibrate function.

Accesses the ID Unknowns function.

Accesses Chromatogram Overlay function.

Navigates through files in Data Review.

Navigates through peaks in “search for peaks”.

Returns to the complete full chromatogram (TIC) display
in “search for peaks”.

Table 8-2 HAPSITE Icons (continued)

Icon

Description
