HAPSITE ER Operating Manual
12.2.4 Analytes
Analytes in Library. . . . . . . . . . . . . Displays the analytes in the library
Analytes in File. . . . . . . . . . . . . . . . Displays the analytes in the currently
displayed or selected file
Search Results in File . . . . . . . . . . If a search has been performed with Search
for Analytes selected, a review of the
analytes detected in the file is enabled.
Individual analytes can then be added to the
template by Right Mouse clicking on the
compound name and then selecting Add To
Template. To add all compounds detected in
the file, select Add All.
12.2.5 Reports
View Calibration Reports:
Calibration Response Table . . Report that displays the response factor and
curve statistics based on the selected curve
type.
Calibration Report . . . . . . . . . . Report that displays the area fit and purity for
the calibration standards.
NIST Search . . . . . . . . . . . . . . . . . . The initial search when building a
template/library is performed using the
AMDIS library. If peaks are detected and
loaded into the template without an
identification, the NIST Search can be used
to identify these compounds.
# . . . . . . . . . . . . . . . . . . . . . . . . . . . . Shows the analyte number in the library
Data Ref. . . . . . . . . . . . . . . . . . . . . . Data Reference, shows the reference to the
Data File in which the analyte was found.
Compound . . . . . . . . . . . . . . . . . . . Shows the compound name that is either
found in AMDIS, found in NIST or assigned
by the user for the analyte.
CAS #. . . . . . . . . . . . . . . . . . . . . . . . Shows the Chemical Abstracts Service
Number for the analyte from the AMDIS or
NIST library.
Q Ion . . . . . . . . . . . . . . . . . . . . . . . . Shows the Quantitation Ion for the analyte.
Ret. Time . . . . . . . . . . . . . . . . . . . . . Show the Retention Time for the analyte.
