Job Menu
R-35
•
2D (HA only) : A motorized total station will turn horizontally
toward the design point after tapping the
7XUQ *XQ button in
the particular stakeout screen.
•
3D (HA and ZA) : A motorized total station will turn
horizontally and vertically toward the design point after
tapping the
7XUQ *XQ button in the particular stakeout
screen.
•
Automatic 2D (HA only) : A motorized total station will
automatically turn horizontally toward the design point when
the stakeout screen opens.
•
Automatic 3D (HA and ZA) : A motorized total station will
automatically turn horizontally and vertically toward the
design point when the stakeout screen opens.
Cut Sheet Offset stored : The cut sheet offset information can be
stored to the raw data file in either of the following formats when
performing any offset staking routine:
•
Design Offset : when selected, a cut sheet report will list the
design-offset values.
•
Actual Offset : when selected, a cut sheet report will list the
measured-offset values.
Repetition Settings
The Repetition Settings card contains the
settings that control how repetition shots are
performed and acceptable tolerances.
Horizontal Tolerance : a warning message will
be displayed if a horizontal angle exceeds the
tolerance entered here during a repetition shot.
Zenith Tolerance : a warning message will be
displayed if a vertical angle exceeds the
tolerance entered here during a repetition shot.
Distance Tolerance : a warning message will be
displayed if a distance exceeds the tolerance entered here during a
repetition shot.
