Appendices
976
Dynamic Modulation Sources (Dmod)
You can control certain effect parameters using the
joystick, vector joystick, ribbon controller, etc. “on the
fly.”
These parameters can also be controlled by KARMA,
the Vector joystick and EG, or the sequencer.
Controlling effects in this way is referred to as
Dynamic Modulation. For example, you can use After
Touch to speed up the LFO of the chorus and flanger,
or you can use the ribbon controller to sweep a wah
effect. This lets you take full advantage of the effects as
part of the expressive potential of your instrument.
Most of the parameters for dynamic modulation
consist of parameter values for Source and Amount.
The Source field selects the modulation source, and
Amount sets the modulation intensity. When the
Source is at its maximum value (for instance, when
JS+Y is moved all the way up), the actual degree of the
effect will be the parameter value plus the Amount.
For example, let’s say that Wet/Dry = 10:90, Source =
After Touch, and Amount = +50.
With no After Touch, the wet/dry balance is 10:90
(mostly dry). As you apply After Touch, the balance
will change to include more of the effect sound, and
less of the dry sound. When After Touch is at its
maximum, the wet/dry balance will be 60:40 (more
wet than dry).
See the individual effects descriptions for explanations
of other dynamic modulation parameters. Parameters
which can be controlled through dynamic modulation
are marked by the
symbol.
Dmod and MIDI
In Program and Sampling modes, dynamic
modulation is always controlled via the global MIDI
Channel.
In Combination and Sequencer modes, dynamic
modulation is controlled via the MIDI channel
independently specified by the “Ch” for IFX1–12,
MFX1, 2, and TFX1, 2.
Dynamic Modulation Source List
Wet / Dry
Max Zero Higher
D -mod
Dry
Wet
60:40
10:90
Dynamic Modulation (Example)
Wet / Dry=10:90
Amt= +50
Wet / Dry=60:40
Amt= –50
Off dynamic modulation is not used
Gate1 note on/off ☞p.977
Gate1+Damper note on + damper on/off ☞p.977
Gate2 note on/off (retrigger) ☞p.977
Gate2+Damper
note on + damper on/off (retrigger)
☞p.977
Note Number note number
Velocity Velocity
Exponential Velocity exponential velocity ☞p.977
After Touch after touch (Channel After Touch)
JS X joystick X (horizontal) direction
JS+Y (CC#01)
joystick +Y (Vertical upward)
direction (CC#01)
JS–Y (CC#02)
joystick –Y (Vertical downward)
direction (CC#02)
Foot Pedal (CC#04)
assignable foot pedal (CC#04)
☞p.977
FX Control1
(CC#12)
MIDI effect control 1 (CC#12)
FX Control2
(CC#13)
MIDI effect control 2 (CC#13)
Ribbon (CC#16) ribbon controller (CC#16)
Value Slider
(CC#18)
value slider (CC#18) ☞p.977
Knob Mod.5
(CC#17) realtime control knob 5 (knob
modulation 5 CC#17)
☞p.977
Knob Mod.6
(CC#19) realtime control knob 6 (knob
modulation 6 CC#19)
☞p.977
Knob Mod.7
(CC#20) realtime control knob 7 (knob
modulation 7 CC#20)
☞p.977
Knob Mod.8
(CC#21) realtime control knob 8 (knob
modulation 8 CC#21)
☞p.977
Knob Mod.5 [+] realtime control knob 5 [+] ☞p.977
Knob Mod.6 [+] realtime control knob 6 [+] ☞p.977
Knob Mod.7 [+] realtime control knob 7 [+] ☞p.977
Knob Mod.8 [+] realtime control knob 8 [+] ☞p.977
Damper (CC#64) damper pedal (CC#64)
Porta. SW (CC#65) portamento switch (CC#65)
Sostenuto (CC#66)
sostenuto pedal (CC#66)
Soft (CC#67) soft pedal (CC#67)
SW1 Mod.
(CC#80) assignable panel switch 1 (SW1
modulation CC#80)
☞p.979
SW2 Mod.
(CC#81) assignable panel switch 2 (SW2
modulation CC#81)
☞p.979
Foot Switch
(CC#82) assignable foot switch (CC#82)
☞p.981
Controller (CC#83) MIDI Control Change (CC#83)
VJS +X
Mod.(CC#85)
Vector joystick +X (VJS modulation
+X CC#85)
☞p.977
VJS –X
Mod.(CC#86) Vector joystick –X (VJS modulation –
X CC#86)
☞p.977
VJS +Y
Mod.(CC#87) Vector joystick +Y (VJS modulation
+Y CC#87)
☞p.977
VJS –Y
Mod.(CC#88) Vector joystick –Y (VJS modulation –
Y CC#88)
☞p.977
Tempo
tempo (internal clock or external
MIDI clock tempo data)
☞p.978
