Delay 094: Stereo BPM Long Delay
843
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level. p.820.
Source [Off…Tempo]
Selects the modulation source for the input level. p.820.
DELAY
BPM [MIDI, 40.00…240.00]
MIDI syncs to the system tempo; 40-240 sets the tempo
manually for this individual effect. p.822.
Time Over? L > [---, OVER!]
Time Over? R > [---, OVER!]
The maximum delay time is 1,360msec per channel
(left and right). If the channel’s combination of BPM,
Base Note, and Times exceeds this limit, the error
message “OVER!” will appear. If this occurs, change
the delay time parameters so that this message no
longer appears.
L Delay Base Note [ … ]
Selects the type of notes to specify the left channel
delay time. p.822.
Times [x1…x32]
Sets the number of notes to specify the left channel
delay time. p.822.
Adjust [%] [–2.50…+2.50]
Fine-adjust the left channel delay time.
R Delay Base Note [ … ]
Selects the type of notes to specify the right channel
delay time. p.822.
Times [x1…x32]
Sets the number of notes to specify the right channel
delay time. p.822.
Adjust [%] [–2.50…+2.50]
Fine-adjust the right channel delay time.
L Feedback [+/–100]
Sets the feedback amount for the left channel.
R Feedback [+/–100]
Sets the feedback amount for the right channel.
Source [Off…Tempo]
Selects the modulation source of feedback amount.
L Amount [+/–100]
Sets the modulation amount of the left channel
feedback.
R Amount [+/–100]
Sets the modulation amount of the right channel
feedback.
High Damp [%] [0…100]
Sets the damping amount in the high range. p.829.
Low Damp [%] [0…100]
Sets the damping amount in the low range. p.829.
OUTPUT
This is the standard effects output section, with
modulatable control over wet/dry balance. For more
information, see “OUTPUT” on page 764.
094: Stereo BPM Long Delay
The stereo delay enables you to match the delay time
with the song tempo. You can set the delay time up to
2,730msec.
INPUT
Input Level Dmod [%] [+/–100]
Sets the modulation amount of the input level. p.820.
Source [Off…Tempo]
Selects the modulation source for the input level. p.820.
DELAY
BPM [MIDI, 40.00…240.00]
MIDI syncs to the system tempo; 40-240 sets the tempo
manually for this individual effect. p.822.
Time Over? L > [---, OVER!]
Time Over? R> [---, OVER!]
The maximum delay time is 2,730msec per channel
(left and right). If the channel’s combination of BPM,
Base Note, and Times exceeds this limit, the error
message “OVER!” will appear. If this occurs, change
the delay time parameters so that this message no
longer appears.
L Delay Base Note [ … ]
Selects the type of notes to specify the left channel
delay time. p.822.
Times [x1…x32]
Sets the number of notes to specify the left channel
delay time. p.822.
Left
Right
Feedback
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp Low Damp
Tempo
BPM
BPM Base Note x Times Adjust [%]
Base Note x Times Adjust [%]
Delay
Delay
