Program mode: HD-1
56
• 3: Swap Oscillators. For more information, see
“Swap Oscillator” on page 144.
2–5: OSC2 Basic
This page controls the basic settings for Oscillator 2. It
is available only when the Oscillator Mode is set to
Double; if not, the page will be grayed out. The parameters are identical to those for Oscillator 1,
as described under “2–1: OSC1 Basic,” on page 48.
2–6: OSC2 Pitch
This page controls the pitch settings for Oscillator 2. It
is available only when the Oscillator Mode is set to
Double; if not, the page will be grayed out. The parameters are identical to those for Oscillator 1,
as described under “2–2: OSC1 Pitch,” on page 53.
2–9: Pitch EG
The Pitch EG, or Envelope Generator, lets you create
complex, time-varying changes to the pitch of
Oscillators 1 and 2. The parameters on this page
control the shape of the EG. For instance, you can:
• Create the basic EG shape by setting the levels and
times of each segment.
• Control the curvature of each EG segment, for
subtle control over the sound of the EG.
• Set up complex modulation of EG levels and times.
• Set up an AMS source, such as an LFO, to restart
the EG.
To control how much effect the EG has on the pitch,
use the Pitch EG parameters on the Pitch Mod page, as
described under “2–2b: Pitch EG,” on page 54.
Differences from the other EGs
The Pitch EG is different from the Filter and Amp EGs
in several ways:
• The single Pitch EG is shared by both Oscillator 1
and Oscillator 2.
• The Sustain level is always 0.
• The Level modulation has two AMS sources
instead of one, and the Time modulation has one
AMS source instead of three.
Pitch EG is also an AMS source
You can use the Pitch EG as an AMS source to
modulate other parameters, just like the keyboard
tracking and LFOs. Simply select the Pitch EG in the
AMS list for the desired parameter.
2–9PMC
2–9a
2–9b
2–9c
2–9d
