OASYS and MIDI CCs Responses to standard MIDI controllers
995
OASYS and MIDI CCs
Responses to standard MIDI controllers
The following table shows how the OASYS responds to
MIDI control change messages, and the relation
between settings and controller movements on the
OASYS.
CC#
0
Bank select (MSB) 0…127 bank select message MSB *1
1 Modulation 1 0…127
corresponds to joystick movement in the +Y direction (Vertical
upward)
2 Modulation 2 0…127
corresponds to joystick movement in the –Y direction (Vertical
downward)
3 – – –
4 Foot controller 0…127
corresponds to when the assignable pedal function is set to
Foot Pedal
5 Portamento time 0…127 portamento time
6 Data entry (MSB) 0…127 MSB of RPN and NRPN data *2
7 Volume 0…127 volume *3
8 Post Insert Effect pan 0…127 pan after the Insert Effect
9 – – –
10 Panpot 0…127 pan
11 Expression 0…127 volume *3
12 Effect control 1 0…127 corresponds to effect dynamic control source FX Control1
13 Effect control 2 0…127 corresponds to effect dynamic control source FX Control2
14 KARMA ON/OFF control
0…63(Off),
64…127(On) Equivalent to on/off when CC#14 is assigned to the KARMA
ON/OFF switches
*7
15 – – –
16 Ribbon controller 0…127 corresponds to ribbon controller operation
17 Knob modulation 5 0…127
corresponds to when Knob Mod.5 is assigned as the REALTIME
knob 5–8
18 Controller (CC#18) 0…127
for control of Alternate Modulation or Effect Dynamic
Modulation
*8
19 Knob modulation 6 0…127
corresponds to when Knob Mod.6 is assigned as the REALTIME
knob 5–8
20 Knob modulation 7 0…127
corresponds to when Knob Mod.7 is assigned as the REALTIME
knob 5–8
21 Knob modulation 8 0…127
corresponds to when Knob Mod.8 is assigned as the REALTIME
knob 5–8
22 KARMA Slider 1 0…127
Equivalent to when CC#22 is assigned to KARMA realtime
control slider 1
*7
23 KARMA Slider 2 0…127
Equivalent to when CC#23 is assigned to KARMA realtime
control slider 2
*7
24 KARMA Slider 3 0…127
Equivalent to when CC#24 is assigned to KARMA realtime
control slider 3
*7
25 KARMA Slider 4 0…127
Equivalent to when CC#25 is assigned to KARMA realtime
control slider 4
*7
26 KARMA Slider 5 0…127
Equivalent to when CC#26 is assigned to KARMA realtime
control slider 5
*7
27 KARMA Slider 6 0…127
Equivalent to when CC#27 is assigned to KARMA realtime
control slider 6
*7
28 KARMA Slider 7 0…127
Equivalent to when CC#28 is assigned to KARMA realtime
control slider 7
*7
29 KARMA Slider 8 0…127
Equivalent to when CC#29 is assigned to KARMA realtime
control slider 8
*7
30 KARMA SCENE 1–8 buttons
0…7(Scene1…8)
, 8…127(invalid) Equivalent to when CC#14 is assigned to the KARMA SCENE
1–8 switches
*7
