Sampling mode

606

Pan (CC#8) (Post IFX PanCC#8)

[L000…C064…R127]

Specifies the panning immediately after the insert
effect.

You can use CC#8 to control this.

Bus Sel. (Bus Select)

[L/R, 1…8, 1/2…7/8, Off]

Specifies the bus to which the signal will be sent
immediately after the insert effect.

L/R: The signal will be output to the L/R bus. Then
after passing through TFX1 and TFX2, it will be output
to AUDIO OUTPUT L/R. This is the normal setting.

1…8: The signal will be output in monaural to the
selected AUDIO OUTPUT (INDIVIDUAL).

1/2…7/8: The signal will be panned by the “Pan
(CC#8)” setting and sent in stereo to the selected
AUDIO OUTPUT (INDIVIDUAL) pair.

Off: The signal will not be sent directly to the L/R or
Individual buses. Use this setting if you want to apply
Send1 and Send2 and then send the signal directly to
the master effects.

FX Control Bus

[Off, 1, 2]

Sends the post-IFX signal to the FX Control buses. See
“8–1d: REC Bus” on page 604.

REC Bus

[Off, 1…4, 1/2, 3/4]

Sends the post-IFX signal to the REC buses. See “8–1d:
REC Bus” on page 604. If you want to resample via the
REC buses, set Source Bus (0–8c) to REC 1/2 or REC
3/4.

Send1

[000…127]

Send2

[000…127]

These adjust the level at which the post-IFX signal is
sent to master effects 1 and 2. This is valid if Bus Select
(8–5a) is set to L/R or Off.

You can use CC#93 to control the Send 1 level, and
CC#91 to control the Send 2 level. The global MIDI
channel specified by MIDI Channel is used for
these messages.

IFX2…12

Here you can specify each insert effect’s effect type,
on/off status, chaining, and mixer settings following
the insert effect. With the exception of Chain to and
Chain, the parameters are the same as for IFX1. See
“IFX1” on page 605.

IFX2: Chain to

[IFX3…IFX12]

IFX3: Chain to

[IFX4…IFX12]

IFX4: Chain to

[IFX5…IFX12]

IFX5: Chain to

[IFX6…IFX12]

IFX6: Chain to

[IFX7…IFX12]

IFX7: Chain to

[IFX8…IFX12]

IFX8: Chain to

[IFX9…IFX12]

IFX9: Chain to

[IFX10…IFX12]

IFX10: Chain to

[IFX11…IFX12]

IFX11: Chain to

[(IFX12)]

These specify the chain destination for each insert
effect. If Chain (check box) is on, the insert effect will
be connected in series to the IFX specified by the Chain
to setting.

8–5b: Resource Meter and Tempo

EXi FIXED

FREE FOR VOICES

The number of voices you can play is affected by how
effects and EXi are being used. This meter shows the
resource allocation as an approximate percentage (%)
of the total processing power.

For more information, see “CX-3 & STR-1: Limitations
on EXi fixed resources” on page 326, and “About
effects resources” on page 727.

(Tempo)

[040.00…240.00, EXT]

This specifies the tempo. This setting is used for
controlling effects, etc.

▼ 8–5: Page Menu Commands

The number before each command shows its ENTER +
number-key shortcut. For more information on these
shortcuts, see “ENTER + 0-9: shortcuts for menu
commands” on page 138.

• 0: Copy Insert Effect. For more information, see

“Copy Insert Effect” on page 149.

• 1: Swap Insert Effect. For more information, see

“Swap Insert Effect” on page 150.

• 2: Insert IFX Slot. For more information, see “Insert

IFX Slot” on page 150.
